APPLYING:
Examining goods and products in terms of presence of iron metals and alloys about the contents iron from the 30%. In all branches of industry. Heavy industry (mines lumber milles), in the chemical industry, food industry. Ideally suited to the study of small products packed in aluminum foil.

FEATURES:

  • Coating metal detector probe SW-2000 is made of stainless steel.The control panel is transparent and designed to maximize illustrate detection place. 8 detection zones allows for fast and the exact location particles of iron. With this solution you can quickly remove impurities.
  • Easy to operate.
  • 8 levels of adjustable sensitivity.
  • Perimeters of steering made in SMD technology.
  • Adapted to powering AC.

SPECIFICATION:

  • SW-2000 model
  • Method of the detection magnetic induction
  • Tenderness at 110mm level is uncovering the steel needle about measurements (0.6 x33mm)
  • Width of detection 520 x 100mm
  • Signalling of the detection - optical-acoustic
  • Power supply: 230VAC-50HZ
  • Power Consumption: 25W
  • Dimension sensor: 520mm (debts) 100mm (wide) 45mm (high)
  • Dimension probes of the detector: 580mm(L) 265mm(W) 105mm(H)
  • Libra of the probe of the detector: 19kg, Control box: 2.65kg
  • The length of the probe can take even 2200mm out. Everything depending on the need of the customer


We provide warranty and post-warranty service.
